Keycloak Integration Guide

If your organization runs Keycloak as a self-hosted identity provider, this integration pulls your directory data into Openlane so you have the user and group context you need for User Access Reviews, onboarding/offboarding evidence, and identity governance.

Key Capabilities

• Client Credentials Authentication: Connects to your Keycloak instance using a confidential client with service accounts enabled — no user credentials stored.
• Directory Metadata Sync: Reads users, groups, and group memberships from your Keycloak realm, giving you the identity baseline for access reviews and audits.
• Flexible Group Sync: Group and membership sync can be disabled independently if you only need user data.

Prerequisites

• A running Keycloak instance with a reachable base URL.
• Keycloak admin access to create a client and assign realm-management roles.

Step-by-Step Setup

Step 1: Create a Keycloak Client for Openlane

1. In the Keycloak admin console, select the realm you want to connect.
2. Navigate to Clients and click Create client.
3. Set a Client ID (e.g. openlane) and click Next.
4. Enable Client authentication and enable Service accounts roles, then click Save.
5. Open the client's Service accounts roles tab and click Assign role.
6. Filter by realm-management and assign at minimum view-users and view-groups.
7. Open the Credentials tab and copy the Client secret — it is only shown once after regeneration.

Step 2: Connect in Openlane

1. Navigate to Organization Settings > Integrations and find Keycloak.

2. Click Configure and enter the required fields:

   Field	Required	Purpose
   baseUrl	Yes	Base URL of your Keycloak instance (e.g. https://keycloak.mycompany.com)
   realm	Yes	The Keycloak realm to sync (e.g. master or your organization realm)
   clientId	Yes	The client ID of the confidential client created in Step 1
   clientSecret	Yes	The client secret from the client's Credentials tab

3. Click Save.

Step 3: Configure Sync Behavior

Optionally configure which data is collected and how records are filtered before ingestion:

Directory Sync

Setting	Description
Primary Directory	Designate this connection as the primary directory source for your organization; the primary directory is the authoritative source that populates the majority of fields on identity holder records
Disable Group Sync	When enabled, only users are synced; groups and memberships are skipped
Filter Expression	Optional Common Expression Language (CEL) expression evaluated against each record; only records that match are ingested (allows inclusion)

Filter expression example:

payload.enabled == true

CEL expressions have access to the full raw payload for each record via payload.<field>.

Validate Connection

After saving, Openlane runs a health check against your Keycloak instance and displays the result on the Installed tab of the Integrations page. You should see a Healthy badge confirming connectivity. If the badge shows Needs Attention, review the troubleshooting section below.

What Openlane Syncs

Openlane reads users, groups, and group memberships from your Keycloak realm. Groups and memberships are skipped when Disable Group Sync is enabled, which is useful if you only need user data.

This data feeds directly into User Access Reviews, onboarding/offboarding verification, and identity scope validation.

Disconnect

To remove this integration:

1. Navigate to Organization Settings > Integrations
2. Select the Installed tab
3. Open the menu on the integration card and select Disconnect
4. In the Keycloak admin console, delete or disable the Openlane client from the Clients list

This removes stored credentials and stops all collection activity. You can reconnect later by configuring the integration again.

Troubleshooting

• Auth failures: verify the client secret is correct and that the client has Service accounts roles enabled.
• URL issues: verify the base URL uses HTTPS and does not include a trailing slash (e.g. https://keycloak.mycompany.com).
• Missing users: verify the client's service account has view-users and view-groups roles assigned under realm-management.
• No group data: confirm that Disable Group Sync is not enabled if you expect group and membership records.

References

• Keycloak documentation
• Keycloak Admin REST API
• Keycloak service accounts
